Art has long stood as a pivotal expression of human creativity, and music is a compact but demanding testbed for embodied artificial intelligence. Most generative AI systems create disembodied content: text, images, audio, or symbolic scores. A robot musician must do something harder. It must understand an incomplete human seed, contribute a complementary musical response, and realize that response through timed physical contact with an instrument.

Co-policy is a modular embodied AI agent for human-robot musical co-creation. It combines semantic intent grounding, constrained musical variation, and a low-latency Gaussian-Mixture Visuomotor Policy (GMP), allowing a chime-striking robot to move beyond playback and participate in physically grounded musical interaction.

A modular embodied co-creation agent

The core challenge is to connect semantic musical understanding with real-time, physically executable action. Co-policy addresses this through three coupled modules: a semantic anchor bank for Qwen-VL, a constrained musical variation planner, and a single-pass mixture-density visuomotor policy for robot execution.

Overview of the Co-policy pipeline

Two streams, one guided attention

Striking the right bell needs two kinds of evidence that pull against each other: the layout of the whole chime frame, and the texture of one bell edge where the mallet has to land. A single token sequence cannot serve both roles, because the long-range terms dominate and fine contact detail is averaged away. Co-policy therefore keeps a global and a local branch separate, and couples them asymmetrically through guided self-attention.

Guided Self-Attention: What The Encoder Looks At

Select a stage to highlight the feature it produces. The maps below are the ones published in the paper, for the same observation.

Egocentric RGB view of the chime rack
O RGB observation
Local feature map with many small high-response patches across bell edges
F1 local, pixel-wise detail
Global feature map with a smooth response spread over the whole chime frame
F2 global, long-range layout
Guided attention map with a single strong response on the target bell
F3 one localized target

Stage detail

A single egocentric RGB frame is the only visual input, and both encoder branches read that same frame. Nothing is discarded by a pre-selected crop or a hand-designed region of interest.

Unlike robotic playback systems that merely reproduce user-specified notes, Co-policy interprets an incomplete creative seed under musical and physical constraints. The semantic anchor bank provides style descriptors, technical annotations, score context, robot-playability tags, and structured target plans. The planner preserves the human motif while introducing harmonic, rhythmic, or accompaniment variation.

Anchored Planning: Answering Instead Of Echoing

A playback robot hands back the notes it was given. The point of anchoring the planner before inference is that the robot instead returns something the human did not play, while still only reaching for bells it can actually strike. Switch the two modes below to compare them on the case worked through in the paper.

BEAT 1 2 3 4 HUMAN plays a motif C4 E4 G4 identical, note for note C4 E4 G4 re-composed over the same beat grid C > G > Am > Em > > accented down-beats, with syncopated accompaniment between them ROBOT answers BELLS camera checked C D E F unavailable G A

The plan never reaches for F, so the arm keeps clear of the blocked bell.

  • new material, not a copy
  • keeps clear of the unavailable bell
What anchoring is worth, scored by ten chime players
0 25 50 75 100 SEMANTIC MUSIC CO-CREATION Qwen-VL 61.6 anchored F-Qwen 74.8 +13.2 CONCERTO CO-CREATION Qwen-VL 51.4 anchored F-Qwen 62.0 +10.6

Retained average scores for the deployed GMP policy, blinded and randomized, with no trimming of high-variance artistic ratings. The two responses above are the ones printed in the paper’s prompt figure, and the unavailable F is that figure’s illustrative instrument state: a bell counts as unavailable when it is unreachable, visually blocked, or still ringing. The released planner does not derive that state, it snaps generated notes to a fixed playable set of all seven chime notes, so treat the bell row as the constraint the anchored planner is asked to respect rather than as output of a shipped detector.

Where the constraint comes from

The mood word is resolved against a small anchor bank before the planner runs. All four anchors are reproduced verbatim from Real_robot/semantic_anchors.json, and the prompt below is the one create_music_prompt() builds in Real_robot/music_creation.py. Highlighted lines are the ones the anchor writes.

Retrieved anchor record
style_descriptor
joyful melody
technical_annotation
allegro moderato, 4/4 time
tempo_range
120 – 140 BPM
robot_playability_tags
short motif clear onset reachable bells
Prompt built for Qwen-VL
You are a musical co-creator for a physical chime-playing robot.
Generate a complementary response rather than copying the human seed.
Return JSON with fields: intent, style, tempo, human_seed, robot_role, available_notes, and robot_notes.

Style anchor: joyful melody - allegro moderato, 4/4 time
Robot playability constraints: short motif, clear onset, reachable bells
Current human seed notes: [Note60 | Note64 | Note67]
User command: play something joyful with me

Anchors are guardrails rather than a lookup table: they fix style, annotation, and playability, while the note sequence itself is still generated. Two details are easy to miss. An unrecognised mood falls back to joyful instead of failing, and tempo_range is kept for the planner but never reaches the prompt, so the two highlighted lines are the only ones the anchor writes. The seed line shows the paper's example motif C4 E4 G4 as MIDI numbers, which is how the prompt builder formats notes; generated notes are afterwards snapped to the seven playable chime notes, C4 through B4.

Why a Gaussian-Mixture Visuomotor Policy?

A single target note can be reached through multiple feasible motions, such as a top-down strike, side swing, or gentle tap. Deterministic behavior cloning tends to average these alternatives, while diffusion-policy execution can preserve multimodality at the cost of repeated denoising. GMP represents these alternatives as latent action modes and predicts mixture parameters in one forward pass.

GMP Inference: One Forward Pass, Several Action Modes

Step through a single inference pass, switch the selection rule, or pick a mode to inspect it. Blobs and bars are clickable.

Schematic, in the same sense as the diagram it reproduces: the component layout and weights illustrate the mechanism and are not measured per-component values. The reported quantitative results are the accuracy and action-frequency figures below.

Evaluating Co-policy on real-robot musical co-creation

We evaluate Co-policy on real-robot chime performance and use ManiSkill2 as a secondary visuomotor generalization sanity check. The real-robot study focuses on whether the agent aligns with human intent, contributes new musical material, executes feasible actions, and responds at interactive speed.

Chime Striking Evaluation
Method Acc Freq
ManiSkill2-style
0.44
15.2 Hz
BC
0.51
10.1 Hz
Diffusion Policy
0.56
1.01 Hz
DROID-adapted BC
0.47
14.2 Hz
Co-policy
0.69
18.6 Hz
combined accuracy post-command action frequency

Table values from the paper: Co-policy reaches 0.69 combined chime-striking accuracy and 18.6 Hz post-command action frequency. The frequency measures the visuomotor execution loop after a robot command is available; it is not a full speech-to-action latency claim.

Where do we go from here?

Co-policy points toward embodied AI systems that can participate in artistic practice rather than only generating disembodied media. The current system is still bounded by the semantic anchor bank, the available instrument, acoustic noise, and limited tactile or force feedback. Future work will extend the framework to richer acoustic source separation, contact feedback, additional instruments, multi-robot ensembles, and longer human-AI improvisation.

The implementation is available in the accompanying GitHub repository, including semantic anchors, the constrained music planner, the real-robot execution loop, and ManiSkill2-based evaluation infrastructure.
